Bosch BGS 52242 [12/134] Cleaning instructions

Figure

If the plate filter is particularly dirty, the dirt can also

be washed off.

a)Turn the bottom part of the filter unit anticlockwise

as far as it will go.

Take the plate filter out of the filter unit.

b)Wash the plate filter under running water.

c)When it has dried completely, insert the plate filter

into the filter unit and lock the bottom part by tur-

ning it clockwise.

Under normal circumstances, and when vacuuming nor-

mal household dust, the plate filter does not need to be

removed or cleaned manually in order to achieve the

vacuum cleaner's optimum power level.

Caution: do not brush the plate filter.

● For simple cleaning without water, simply tap the fil-

ter around the edge of the cap.

● For more thorough cleaning, rinse the filter from the

outside with water, and allow it to dry completely

before using it in the vacuum cleaner again.

Cleaning the fluff filter

The fluff filter should be cleaned at regular intervals in

order to ensure optimum operation of the vacuum clea-

ner.

Figure

● Open the appliance lid and remove the dust contai-

ner from the appliance.

Figure

a)Take the filter unit out of the dust container.

b) Clean the fluff filter.

● It is usually sufficient to lightly shake or tap out the

filter housing when the dust container is emptied to

dislodge any particles of dirt.

● If this is not sufficient, you can use the brush which

is supplied with the appliance or a dry cloth to remo-

ve dirt particles from the surface.

● If you want to wash the fluff filter, you must first

remove the plate filter from the filter unit. The plate

filter must only be reinserted into the filter unit after

the fluff filter has completely dried.

Cleaning the motor protection filter

The motor protection filter should be cleaned regularly

by knocking out the dirt and rinsing.

Figure

a)Open the appliance lid and remove the motor protec-

tion filter.

b)Clean the motor protection filter by tapping out the

dirt. If it is very dirty, the motor protection filter

should be rinsed. Then allow the filter to dry comple-

tely.

c)After cleaning the motor protection filter, reinsert it

into the appliance and close the appliance lid.

Cleaning the exhaust filter

The exhaust filter is designed so that it does not need

to be replaced, provided the appliance is used as inten-

ded in the household.

To ensure that the vacuum cleaner is working at its

optimum power level, the exhaust filter should be rin-

sed out after 1 year. The filtering action of the filter

remains intact, even if the filter surface becomes dis-

coloured.

Cleaning the HEPA filter

Figure

● Open the appliance lid and remove the dust contai-

ner.

Figure

a)Use the locking tab to open the side flap.

b)Pull the two locking tabs to unlock the filter unit with

HEPA filter and remove it from the appliance.

c)Tap out the filter unit and rinse it under running

water.

d)Only reinsert the filter unit into the appliance after it

has dried completely and ensure that it audibly clicks

into place.

e)Close the side flap until you hear the locking tab

click into place again.

f) Insert the dust container into the appliance and

close the appliance lid.

Cleaning the micro filter

Figure

● Open the appliance lid and remove the dust contai-

ner.

Figure

a)Use the locking tab to open the side flap.

b)Pull the two locking tabs to unlock the filter unit with

foam filter and micro filter and remove it from the

appliance.

c)Remove the foam filter and micro filter from the filter

frame.

d)Foam filter and micro filter and rinse it under running

water.

e)Do not re-insert the foam filter and the micro filter

into the filter frame until it has dried completely

f) Insert the filter unit in the appliance and ensure that

the locking tabs audibly click into place.

g)Close the side flap until you hear the locking tab

click into place.

h)Insert the dust container into the appliance and

close the appliance lid.

Cleaning instructions

Always switch off the vacuum cleaner and disconnect

the power cord from the mains before cleaning the

vacuum cleaner. The vacuum cleaner and plastic acces-

sories can be cleaned with an ordinary plastic cleaner.

Caution: do not use a scourer, glass-cleaning agent

or multipurpose cleaning product. Never immerse

the vacuum cleaner in water.

Subject to technical modifications.

28*

29*

*dependent on model
