wood, plastic and metal, as well as to screw and loosen
screws, bolts, etc.
4. TOOL COMPONENTS (Fig. 1)
1. Additional handle
2. Depth stop
3. Universal tool holder
4. LED lamp
5. Battery lock
6. Control button of the state of battery charge
7. Indicators of the state of battery charge
8. Clamping screw
9. Step speed selector switch
10. Ventilation slots
11. Torque regulator
12. Reverse switch
13. On / off switch
14. Belt clip
15. Battery
16. Charger
20. Keyless chuck
21. Function switch
23. Screwdriver bit
24. Screw
26. Label
27. Indicator (red)
28. Indicator (green)
5. STANDARD ACCESSORIES
- Impact screwdriver
- Battery 2 or 4 A
h
(depending on model)
- Charger
- Screwdriver bit
- Belt clip
- Depth stop
- Additional handle
- Operating instructions
- Warranty
6. POWER TOOL ELEMENTS INSTALLATION AND
REGULATION
Before carrying out any procedure, centre the rotatio-
nal direction selector switch (8) to lock the switch and
prevent the tool's untimely start-up.
Do not over tighten the calibration
elements to avoid damaging the thread.
Assembly/tool replacement
With intensive use the drill bit can become
very hot. Use gloves to remove the bit.
• Open the chuck jaws (20) by turning the front part,
as shown in (Fig. 4).
• Assemble/replace drill or bit.
• Tighten the chuck (20), as shown in (Fig. 4).
Screwdriver bits/magnetic support (Fig. 7)
Use a magnetic support (not included) for short screw-
driver bits, so they are securely fixed (Fig. 7)
The magnetic support is not necessary if double-ended
bits are used, especially for screwdrivers.
Additional handle (see Fig. 2)
It's recommended use the additional handle 1 when
operating. Additional handle 1 may be positioned as
deemed comfortable by the user.
• Loose additional handle 1 as shown in (Fig. 2).
• Place additional handle 1 in desired position.
• Tighten additional handle 1 as shown in (Fig. 2).
Depth stop (see Fig. 3)
Use depth stop 2 to set a required drilling depth (see Fig. 3).
• Slacken clamping screw 8 (see Fig. 3.1).
• Touch the wall with the end of the drill bit and move
the depth stop 2 until its end touches the wall, as
shown in (Fig. 3.1).
• Move depth stop 2 back to set a required drilling depth
(distance "a") (see Fig. 3.2).
• Tighten clamping screw 8 and drill the hole (see Fig. 3.3).
• To mount the keyless chuck 20, carry out the operations
in consecutive stages as it is shown in (Fig. 5).
• To dismount the keyless chuck 20, carry out the ope-
rations in consecutive stages as it is shown in (Fig. 6).
keep in mind that in the process of mou-
nting / dismounting of the keyless chuck
20 the screw 24 has a left-hand thread.
Screwdriver bit / magnetic holder (see Fig. 7)
For short screwdriver bits use the magnetic holder 25
for their reliable fixing (see Fig. 7).
A magnetic holder 25 is not needed for extended
screwdriver bits 23 (specially purposed for screwdrivers)
7. HOW TO CHARGE THE BATTERY
Initial operating of the power tool
The power tool's battery comes partially charged. The
battery must be fully charged before the first use.
Charging process (Fig. 3)
• Press the battery lock 5 and remove the battery 15
(see Fig. 8.1).
• Connect the charger 16 to the power supply.
• Insert battery into charger (see Fig. 8.2).
