3. Set the starting & stopping time
3.1 Push the TIMER ON button, the remote controller will show
TIMER ON, the last set time for START operation and the
signal "h" will be shown on the DIGITAL display area. You
are now ready to readjust the TIMER ON to start the operation.
3.2 Push the TIMER ON button again to set the time you want to
start the operation.
3.3 Push the TIMER OFF button, the remote controller will show
TIMER OFF, the last set time for STOP operation and the
signal "h" will be shown on the DIGITAL display area. You
are now ready to reset the time to STOP operation.
3.4 Push the TIMER OFF button again to set the time you want to
stop the operation.
3.5 After setting the TIMER, there will be a one-half second delay
before the remote controller transmits the signal to the Air
Conditioner. Then , after approximately another 2 seconds, the
signal "h" disappears and the set temperature will re-appear on
the digital display.
To change the TIMER ON/OFF time, just press the corresponding
TIMER button and reset the time.
To cancel the TIMER ON/OFF setting, just adjust the TIMER time
to 0:00.
Change the TIMER
NOTE
The setting time is relative time. That is the time set is based
on the delay of the current time.
!
1. Be sure there are no obstacles between the remote controller
and the receiver of indoor unit otherwise the air conditioner will
not work.
2. Keep the Remote Controller away from any liquids.
3. Protect the remote controller from the high temperatures and
exposure to radiation.
4. Keep the indoor receiver out of direct sunlight or the Air Condi-
tioner may malfunction.
5. Keep Remote Controller away from EMI(Electro-Magnetic
Interference) supplied by other household appliances.
Warning
7
