Mi Robot Vacuum-Mop SKV4093GL [7/95] Routine maintenance

Routine Maintenance

Dust Bin and Filter

Note: Weekly cleaning is recommended.

1. Open the vacuum-mop cover, then pinch the bin clips to remove the

dust bin.

Cleaning the Washable Filter

Note: Biweekly cleaning is recommended.

1. Open the bin cover at the positions marked with arrows.

Note: Only clean water should be used to clean the ﬁlter. Do not use detergent.

Do not aempt to clean the ﬁlter with a brush or ﬁnger.

2. Add clean water to the dust bin, and close the bin cover, then shake

the bin back and forth, ﬁnally pour out the water. Repeat these steps

until the ﬁlter is clean.

2. Open the bin cover as indicated by the diagram.

Using the Brush Cleaning Tool

Main Brush Guard

Clips

Main Brush

Bearings

＞0.5m

＞1.5m

＞0.5m

Note: Do not place the charging dock in an area with direct sunlight or where other objects could

block its signaling area, as this may hinder the vacuum-mop from returning to the charging dock.

Charging Dock

Place the charging dock on the level ground against a wall. Before

plugging the charging dock into a power outlet, make sure there is a

distance of 0.5 meters or more on either side of the charging dock. To

ensure you can well connect to the vacuum-mop with your phone,

make sure the vacuum-mop and charging dock are in the range of

Wi-Fi.

Main Brush

1. Flip the vacuum-mop over and pinch the clips to remove the main

brush guard.

2. Li the main brush out of the vacuum-mop, then clean the brush

bearings.

3. Use the included brush cleaning tool to remove any hairs tangled on

the brush.

4. Reinsert the main brush, then put the guard back on and press on it

until the clips lock into place.

Note: It is recommended to clean the main brush weekly and replaced

every 6 to 12 months.

11 12
