Grillo Climber 9.27 [10/47] Technical specifications

Climber 9.27/ Translation of the original instructions

RECOMMENDED LIST OF SPARE PARTS TO BE KEPT IN STORE

2 x cutting blades

2 x blade screws

2 x blade screw nuts

1 x set of belts

1 x air filter for engine

1 x oil filter for engine

TECHNICAL SPECIFICATIONS

ENGINE: BRIGGS & STRATTON 8270 Series, OHV, 724cc twin-cylinder petrol version equipped with vertical

shaft and Cyclonic air filter.

FUEL TANK: 13 Litres – EMERGENCY SUPPLY: 3 litres.

STARTER: electric with 12V battery.

GEARBOX: hydrostatic transmission with reduction gear and differential.

DIFFERENTIAL LOCK: with pedal engagement.

CLUTCH: electromagnetic with P.T.O and with blade brake.

SPEED: continuously variable from 0 to 11,5 km/h + reverse speed from 0 to 7,5 km/h.

TYRES: TRACTOR front 3,50-6 puncture-proof treated; rear: 18×9.50-8.

BRAKES: front service brakes with pedal engagement; rear parking brake with lever engagement.

SEAT: sprung and adjustable super-comfort seat with foldable roll-bar.

CUTTING DECK: rear/side discharge.

CUTTING SYSTEM: rotating with 1 blade with swinging tips and double cutting edge.

CUTTING WIDTH: 98 cm.

CUTTING HEIGHT: from 3,5 cm to 13,5 cm with continuous adjustment.

HOURLY CUTTING CAPACITY: approx. 8000 m2/h.

INTERNAL STEERING RADIUS: 70 cm.

STANDARD FEATURES: tow bar.

ATTACHMENTS: dampened seat support, snow chains for rear wheels.

WEIGHT: 358 kg

SIZE:

Length: 196 cm

Width: 108 cm

Height: 95 cm (with folded roll-bar)

Distance between the axles: 133 cm
