Climber 9.27/ Translation of the original instructions
PUTTING THE MACHINE INTO SERVICE
1) Check that the machine has not been damaged during transport.
2) Check the oil levels of the engine (fig. 2), hydrostatic transmission (fig. 3) and final driven (fig. 11A).
3) Check the tyre pressure:
– 1 BAR front wheels 3×5.00-6
– 1.5 BAR rear wheels 18×9.50-8
4) Check the battery voltage; it must be at least 12,5 Volts. If necessary, charge the battery with a
battery charger set at 12 volts on slow charge for 2 hours. IMPORTANT! During assembly take care
not to reverse the polarity of the battery.
BATTERY – CAUTION!
The gases released by the battery are explosive, keep it away from open flames or sparks. Check the
liquid level periodically and keep the terminals lubricated with appropriate grease.
RUNNING IN – CAUTION!!
Change the engine oil and filter after the first 20 working hours. Check that there are no oil leaks or
loosen screws, especially those which fix the blade, the steering and the wheels. Adjust the tension of
the hydrostatic transmission belts (fig. 16).
INSTRUCTIONS FOR USE
BEFORE STARTING UP THE ENGINE
Before starting up the engine, always check that:
– the engine oil level is correct (fig. 2)
the oil in the hydraulic engine is at the correct level (fig. 3)
the forward level is in neutral position (fig. 1B, no. 2)
the engine cooling intake grids are clean (fig. 5)
– air filter is clean (fig. 6)
– the cutter deck is clean
– the hydraulic engine fins are clean (fig. 7)
– the blades are sharp and firmly fastened in place
– the screw in the centre of the blade hub is safely tightened (fig. 1C, no.3)
Fill the fuel tank using a funnel with very fine filter (fig. 1A, no. 4).
STARTING THE ENGINE
– Push the throttle to the max. if the engine is cold (fig. 1B, no.5).
– Turn the ignition key on the dashboard (fig. 1, n. 7).
– Once the engine has started wait for a few minutes to allow the engine to warm up.
– To switch off the engine put the ignition key in the STOP position (fig.1, no. 7).
Important: When transferring with the brush-cutter keep the cutter deck at the maximum height setting.
STARTING WORK
– Choose the cutting height using the lever (fig. 1D, no. 8). Speed up the engine as indicated in the label
PTO-START and engage the PTO lever (fig. 1, no. 1). Gently operate the forward lever (fig. 1B, no. 2)
and start work.
To stop, return the forward lever to the stop position. The forward lever can be returned to the stop
position by pushing the brake pedal too (fig. 23, no. 1).
– The lever (fig. 1B, no. 2) is also used to reverse. When it is moved back, the machine moves
backwards – always operate it gently. Releasing the lever, this turns back automatically to the neutral
position.
