Climber 9.27/ Translation of the original instructions

Uneven cutting

– Cutting deck not parallel to ground – Check tyre pressure

– Level off the deck

– Blades fault – Check that the blades are correctly mounted

– Sharpen or change the blades

– Check the tension of the cutting deck

engine belt

Vibrations during operation

– Blades unbalanced – Balance blades or replace if damaged

– Fastenings are loose – Check and fasten the blade fixing screws

as well as the fixing screws of the engine

and chassis.

Incorrect P.T.O. engagement

– Check the battery voltage, it must be at least

12,5 volts

– Check the levelness of the blade brake and the

electromagnetic clutch, 0,3 mm

ELECTRICAL SYSTEM

The electrical system is protected by a fuse which cuts out the entire electrical system if blown. After

finding and repairing the fault, replace the fuse with another of the same rating. Never replace the

fuse with one of a different rating. The electrical system fuses are underneath the tank (fig. 19). If the

problems persist after all the procedures described above have been carried out, contact an authorized

service centre. Never attempt to make difficult repairs unless you have the necessary equipment and

technical expertise.

ELECTRONIC CONTROL UNIT

Inside the steering column there is an electronic control unit (fig. 19A) that controls all the electric

functions of the machine (e.g. PTO, safety micro-switches).

IMPORTANT!

– Take care not to reverse the battery polarity.

– Never operate the mower without the battery, since it is equipped with a charge regulator.

– Take care not to cause short-circuits.

THE MACHINE DOES NOT REMAIN IN NEUTRAL

Adjust the zero turn device by tightening or loosening it (fig. 17). to adjust the forward and reverse travel

speeds, use the screws (fig. 18).

END OF WORK

After mowing, disengage the blades and drive back to base with the cutter deck in the highest position.

To stop, move the forward lever to the STOP position (fig. 1B, no. 2), set the throttle lever at the

minimum r.p.m., switch off the engine by turning the key on the STOP position (fig. 1, no.7) and lower the

deck to the lowest position. Lock the park brake (fig. 23, no. 2).

CLEANING

Clean the outside of the brush-cutter after each use.

– When PTO button is pressed,

The blade does not engage
