![Grillo GH 9 [7/71] Hydrostatic all purpose flails](/views2/1651325/page7/bg7.png)
Translation of the Original Instructions
HYDROSTATIC ALL PURPOSE FLAILS
GH 7 – GH 9
Dear customer,
Thank you for choosing our hydrostatic all purpose flail GH7 – GH9. We are sure that the
performance of your new machine will fully meet your requirements. To ensure optimum
performance and maintenance, please read this manual carefully and follow its instructions. This
will enable you to obtain the best results and protect your investment. This manual should always
be kept with the machine.
GENERAL DESCRIPTION AND INTENDED USE
The all purpose flail is a single-axle self-propelled machine equipped with an all purpose flail to cut
grass in rough areas and on slopes (max. 20 °). This machine is built on a frame fitted with a petrol
engine. The engine drives the wheels and P.T.O, which is usually connected to a rotary all purpose
flail. Other implements can be connected to the P.T.O such as snow throwers, cutter bars and
pivoting brushes. This machine is a pedestrian-controlled machine, the operator steers the
machine via the handle-bar where the controls are located.
CAUTION! Before starting the engine, read this carefully. The following warnings
are very important to ensure the operator's safety!
WARNINGS
Caution is the main safeguard in preventing accidents. We urge you to read the warnings that
follow when using the all purpose flail, before starting any work at all. Improper use of the all
purpose flail and its equipment can be dangerous. To reduce the risks to the minimum, observe the
necessary precautions set out below:
1) Read the whole of this manual before using your all purpose flail. Be thoroughly familiar with the
controls and the proper use of the machine before starting.
2) Pay special attention to the safety warnings and labels.
3) The rotating all purpose flail is extremely dangerous; never insert hands or feet under the all
purpose flail!
4) Before other people are allowed to use the machine, make sure they are informed about the
safety regulations and how to properly use this equipment.
5) Ensure children and animals are kept at a safe distance of about 15 metres. Do not allow people
to come closer to the all purpose flail when it is being used.
6) Never allow the machine to be used by anyone under 16 years of age.
7) Do not use the machine when physically fatigued or under the influence of alcohol or drugs that
could impair the operator's physical and mental capacities.
8) Thoroughly check the ground before using the all purpose flail and remove any object that could
damage the tines (e.g. stones) or that could be caught up and flung down, therefore becoming
highly dangerous. (e.g. branches, stones).
9) Always wear suitable clothing and footwear. It is recommended to wear safety footwear,
safety goggles, ear plugs and gloves, long trousers. Do not wear clothing or accessories
that could get trapped in the controls or in the all purpose flail (e.g. loose trousers,
scarves…).
10) Never run with the machine.
11) Pay close attention when working on slopes. Always work across the slope and never
upwards/downwards. Pay greater attention when changing direction on slopes and never work on
excessively steep ground (max. 20°).
12) Pay close attention when lifting the machine from the ground or when putting it on the ground.
