SILICON EXPITAXIAL PLANAR SWITCHING DIODE
BAS16WS
SOD-323
PLASTIC PACKAGE
Marking
BAS16WS = A6 with cathode band
Fast Switching Diode
ABSOLUTE MAXIMUM RATINGS
DESCRIPTION SYMBOL UNIT
Continuous Reverse Voltage
V
R
V
Repetitive Peak Reverse Voltage
V
RRM
V
Forward Current (Continuous)
I
F
mA
Non Repetitive Peak Forward Current
t=1µµs
I
FSM
A
t=1ms
I
FSM
A
t=1s
I
FSM
A
Power Dissipation @ T
amb
=25ºC P
tot
mW
Junction Temperature
T
j
o
C
Storage Temperature Range
T
stg
o
C
THERMAL RESISTANCE
Junction to Ambient in free air
R
th (j-a)
o
C/W
ELECTRICAL CHARACTERISTICS (T
amb
DESCRIPTION SYMBOL TEST CONDITION MIN TYP MAX UNIT
Forward Voltage
V
F
I
F
= 1 mA
0.715 V
I
F
= 10 mA
0.855
V
I
F
= 50 mA
1.0
V
I
F
= 150 mA
1.25
V
Reverse Voltage Leakage Current
I
R
V
R
=25V, T
j
=150ºC 30
µA
V
R
=75V
1.0
µ
A
V
R
=75V, T
j
=150ºC
50
µ
A
Diode Capacitance
C
d
V
R
=0V, f=1MHz
2.0 pF
Reverse Recovery Time When Switched
from
t
rr
I
F
=10mA to
I
R
=60mA, R
L
100 Ω,
Measured at I
R
=1mA
6.0 ns
BAS16WS Rev140604E
150
650
VALUE
75
100
- 65 to 150
0.5
250
200
2.0
1.0
Continental Device India Limited
Data Sheet Page 1 of 3
Continental Device India Limited
An ISO/TS 16949, ISO 9001 and ISO 14001 Certified Company
