CDIL 2N3055-CDI [4/5] To 3 metal can package

Continental Device India Limited

An ISO/TS 16949, ISO 9001 and ISO 14001 Certified Company

TO-3 Metal Can Package

TO-3 100 pcs/pkt 1.3 kg/100 pcs 12.5" x 8" x 1.8" 0.1K 17" x 11.5" x 21" 2K 27.5 kgs

PACKAGE

Net Weight/QtyDetails

STANDARD PACK INNER CARTON BOX

Qty

OUTER CARTON BOX

Qty Gr WtSize Size

Packing Detail

All dimens

DIM

MIN.

MAX.

—

39.37

B —

22.22

C 6.35 8.50

D 0.96 1.09

E — 1.77

29.90

30.40

10.69

11.18

H 5.20 5.72

16.64

17.15

11.15

12.25

L —

26.67

M 3.84 4.19

PIN CONFIGURATION

1. BASE

2. EMITTER

3. COLLECTOR

2N3055_MJ2955 Rev 1 01042014E

Continental Device India Limited

Data Sheet

Page 4 of 5
