D - KIMWC00211-09EN - 13/58
TECHNICAL SPECIFICATIONS
EWLD-DJYNN / EWLD-DJYNN + OPLR
360 380 420 480 550
Capacity
(1)
Cooling kW 352.2 381.1 428.3 475.7 525.9
Type Stepless
Capacity control
Minimum capacity % 12.5 12.5 12.5 12.5 12.5
Unit power input
(1)
Cooling kW 99.7 108.6 120.0 131.5 148.0
EER
(1)
3.53 3.51 3.57 3.62 3.55
Colour RAL7032
Casing
Material Galvanized and painted steel sheet
Height mm 1942 1942 1942 1942 1942
Width mm 1100 1100 1100 1100 1100
Dimensions Unit
Depth mm 4400 4400 4400 4400 4400
Unit
(2)
kg 2446 2446 2501 2506 2506
Weight
Operating Weight
(2)
kg 2560 2560 2670 2670 2670
Type A fascio tubiero
Water volume l 113 113 173 168 168
Nominal water flow Cooling l/s
16.8 18.2 20.5 22.7 25.1
Nominal water
pressure drop
Cooling kPa
18.3 21.1 29.6 35.9 42.8
Water heat exchanger
Evaporator
Compressor
Insulation material Closet cell foam elastomer
Liquid receiver Volum 170 l
Type Semiermetici singola vite
Oil charge
(3)
l -- -- -- -- --
Sound level
Quantity 2 2 2 2 2
Sound power
(4)
Cooling dBA
90.5
90.5
90.5
90.5
90.5
Refrigerant circuit
Sound pressure
(4)
Cooling dBA
71.7 71.7 71.7 71.7 71.7
Refrigerant type
R134a R134a R134a R134a R134a
Refrigerant charge
(5)
kg -- -- -- -- --
Refrigerant circuit
No. of circuits 2 2 2 2 2
Piping connections Evaporator water inlet/outlet mm 114.3 114.3 139.7 139.7 139.7
Safety devices High pressure (pressure switch)
Safety devices Low pressure (pressure switch)
Safety devices Emergency stop
Safety devices High discharge temperature on the compressor
Safety devices Phase monitor
Safety devices Low pressure ratio
Safety devices High oil pressure drop
Safety devices Low oil pressure
Notes
(1)
Nominal cooling capacity and power input are based on: 12/7 °C entering/leaving evaporator water
temperature; 45 °C saturated discharge temperature at the compressor
(2)
Shipping and unit weight figures are related to the unit without sound proof cabinet
(3)
EWLD-DJYNN (+OPLR) version units with 3 l of oil precharged. Oil quantity must be defined by plant
designer only
(4)
Power and Pressure sound levels are referred to the unit without sound proof cabinet. Pressure
sound levels values with sound proof cabinet table at page 12
(5)
EWLD-DJYNN (+OPLR) version units are precharged with 5 kg of gas refrigerant. Refrigerant charge
must be defined by plant designer only
