D - KIMWC00211-09EN - 9/58
TECHNICAL SPECIFICATIONS
EWWD-DJYNN
380 420 460 500 600
Capacity
(1
)
Cooling kW 372,2 402,5 448,3 493,7 555,7
Type
Capacity control
Minimum capacity % 12,5 12,5 12,5 12,5 12,5
Unit power input
(1
)
Cooling kW 93,1 101,4 115,1 129,0 150,2
EER
(1
)
4.00 3.97 3.89 3.83 3.70
ESEER
5.33 5.29 5.19 5.10 4.93
Colour RAL7032
Casing
Material Galvanized and painted steel sheet
Height mm 1880 1880 1880 1880 1880
Width mm 860 860 860 860 860
Dimensions Unit
Depth mm 4305
4305
4305
4305
4305
Unit
(2)
kg 2697 2702 2757 2762 2762
Weight
Operating Weight
(2)
kg 2850 2860 2970 2970 2970
Type
Water volume l 113 113 173 168 168
Nominal water flow
rate
Cooling l/s
17.8 19.2 21.4 23.6 26.6
Nominal Water
pressure drop
Cooling kPa
61.9 71.0 54.2 54.2 67.3
Water heat exchanger
Evaporator
Insulation material Closet cell foam elastomer
Type Shell and tubes
Number of condensers No. 113 113 173 168 168
Water volume l 28 30 30 30 30
Nominal water flow
rate
Cooling l/s 22.2 24.1 26.9 29.8 33.7
Nominal Water
pressure drop
Cooling kPa 41.2 41.4 58.4 60.7 75.8
Water heat exchanger
Condenser
Insulation Material Closet cell foam elastomer
Type Semihermet. single screw compr.
Oil charge l 32 32 32 32 32
Compressor
Quantity 2 2 2 2 2
Sound Power
(3)
Cooling dBA
90.2 90.2 90.2 90.2 90.2
Sound level
Sound Pressure
(3)
Cooling dBA
71.7 71.7 71.7 71.7 71.7
Refrigerant type R134a R134a R134a R134a R134a
Refrigerant charge kg 100 100 100 100 100
Refrigerant circuit
N. of circuits 2 2 2 2 2
Piping connections Evaporator water inlet/outlet mm 114.3 114.3 139.7 139.7 139.7
Pipinogconnections Condenser water inlet/outlet inch 5 5 5 5 5
Safety devices High pressure (pressure switch)
Safety devices Low pressure (pressure switch)
Safety devices Emergency stop
Safety devices High discharge temperature on the compressor
Safety devices Phase monitor
Safety devices Low pressure ratio
Safety devices High oil pressure drop
Safety devices Low oil pressure
Notes
(1)
At the following nominal conditionsthe: evaporator 12°C/7°C; condenser 30/ 35°C.
(2)
Operating and Unit weight are referred to the unit without sound proof cabinet
(3)
Power and Pressure sound levels are referred to the unit without sound proof cabinet. Pressure
sound levels values with sound proof cabinet table at page12
