D - KIMWC00211-09EN - 31/58
Table 7 Electrical Data EWLD-DJYNN / EWLD-DJYNN + OPLR
Unit Compressors Control
Unit Size Max.
current for
wires
sizing
Max. startup
current (1)
Power
factor (2)
Size of
disconnecting
switch
Corrente di
cortocircuito
Icc
Number of
compressors
Max. current of
compressors Circ.1/ Circ.2
(3)
Peak current of
compressors Circ.1/ Circ.2
Size of type gG NH0/NH1
compressor fuses Circ.1/
Circ.2
A A A kA A A A A A A VA A
160
123 288 0.83 250 A 13.5 1 112 288 125 500 4
190
147 288 0.87 250 A 13.5 1 134 288 160 500 4
240
177 288 0.89 250 A 13.5 1 161 288 200 500 4
280
200 288 0.89 250 A 13.5 1 182 288 250 500 4
320
246 381 0.83 400 A 25 2 112 112 288 288 125 125 500 4
360
271 396 0.85 400 A 25 2 112 134 288 288 125 160 500 4
380
295 396 0.87 400 A 25 2 134 134 288 288 160 160 500 4
420
325 418 0.88 400 A 25 2 134 161 288 288 160 200 500 4
480
354 418 0.89 400 A 25 2 161 161 288 288 200 200 500 4
550
400 453 0.89 630 A 25 2 182 182 288 288 250 250 500 4
(1) Startup current of the biggest compressor + current at 75% of the other compressors at maximum conditions
(2) Power factor of compressors under nominal conditions (12/7°C – 30/35°C – 400V)
(3) FLA compressors
