D - KIMWC00211-09EN - 29/58
Table 5 Electrical Data EWWD-DJYNN
Unit Compressors Control
DJYNN
Max.
current for
wires
sizing
Max. startup
current (1)
Power
factor (2)
Size of
disconnecting
switch
Shortcircuit
current
Icc
Number of
compressors
Max. current of
compressors Circ.1/ Circ.2
(3)
Peak current of
compressors Circ.1/ Circ.2
Size of type gG NH0/NH1
compressor fuses Circ.1/
Circ.2
A A A kA A A A A A A VA A
170
123 288 0.83 250 A 13.5 1 112 288 125 500 4
210
147 288 0.87 250 A 13.5 1 134 288 160 500 4
260
177 288 0.89 250 A 13.5 1 161 288 200 500 4
300
200 288 0.89 250 A 13.5 1 182 288 250 500 4
320
246 372 0.85 400 A 25 2 112 112 288 288 125 125 500 4
380
271 386 0.87 400 A 25 2 112 134 288 288 125 160 500 4
420
295 386 0.87 400 A 25 2 134 134 288 288 160 160 500 4
460
325 404 0.88 400 A 25 2 134 161 288 288 160 200 500 4
500
354 404 0.89 400 A 25 2 161 161 288 288 200 200 500 4
600
400 415 0.89 630 A 25 2 182 182 288 288 250 250 500 4
(1) Startup current of the biggest compressor + current at 75% of the other compressors at maximum conditions
(2) Power factor of compressors under nominal conditions (12/7°C – 30/35°C – 400V)
(3) FLA compressors
