2. Connector, Switch References

2.1 Connector Index

Reference

Designation

Functional Description Connector Type

SW1

Power Button

(TF) Push Button Switch.HCH.PTS-099

CN1

RTC Battery Wafer

(TF) WAFER BOX 2P.180D.1.25mm.CATCH.1201-700-02S

CN31

MIPI DSI Connector

(TF)FPC/FFC Conn.41P.90D(F).0.6mm.Hirose.FH35C-41S-0.3SHW(50)

CN32

MIPI CSI Connector

(TF)FPC/FFC Conn.21P.90D(F).0.6mm.Hirose.FH35C-21S-0.3SHW(50)

CN6

USB 3.0 Micro Connector

(TF) Micro USB 3.0 Conn.10P.90D.B-type.ATTEND.209E-BE01

CN7 USB 2.0 1x10P Wafer (TF)Wafer Box.10P.90D.1.0mm.CATCH.1204-700-10RM

CN8 USB Type A Connector 1 (TF)USB CONNECTOR DUAL PORT.8P.TechBest.KS-002D-ANB(2.0)-L

CN9

USB Type A Connector 2

(TF)USB CONNECTOR DUAL PORT.8P.TechBest.KS-002D-ANB(2.0)-L

CN10

RJ45 LAN Connector

(TF) RJ45.14P.90D.W/TF & LED.UDE.RB1-1A5BAK1A

CN11

HDMI Connector

(TF)HDMI CONN.19P.90D(F).A TYPE.FOXCONN.QJ51191-LFB4-7F

CN12

HAT 40 GPIO Connector

(TF) PIN HEADER.2*20P.180D.(M).2.54mm.DIP

CN14 Reset Pin Header (TF) PIN HEADER.2*1P.180D.(M).2.0mm.DIP

CN30 DC Jack (TF)DC Power Jack.3P.90D(M).DIP.2.0mm.COXOC.416AEWTJ02004PA

CN34

Update CPLD Header

(TF)PIN HEADER.6*2P.180D(M).1.27mm.Astron.C27-4112-206-1G-R

CN33

Power Button Wafer

(TF)WAFER BOX.2P.180D.(M).1.25mm.CATCH.1201-700-02S
