AAEON UP-CHT01-A10-0432 [12/14] Cn12 hat 40 gpio connector

www.up-board.org

-12-

3 DDI2_TX0_HDMI_DN- 13 HDMI_CEC_D

4 DDI2_TX1_HDMI_DP+ 14 NC

5 GND 15 DDI2_DDC_CLK

6 DDI2_TX1_HDMI_DN- 16 DDI2_DDC_DAT

7 DDI2_TX2_HDMI_DP+ 17 GND

8 GND 18 +5V_HDMI

9 DDI2_TX2_HDMI_DN- 19 DDI2_TYPE_C_HPD

10 DDI2_CLK_HDMI_DP+

4.10 CN12: HAT 40 GPIO Connector

Pin Signal Description Pin Signal Description

1 +3.3V 2 +5V

3 I2C1_SDA 4 +5V

5 I2C1_SCL 6 GND

7 ISH_GPIO0 8 UART_TX

9 GND 10 UART_RX

11 SD2_CMD 12 I2S_CLK

13 SD2_CLK 14 GND

15 SD2_SD0 16 SD2_SD1

17 +3.3V 18 SD2_SD2

19 SPI2_MOSI 20 GND

21 SPI2_MISO 22 SD2_SD3

23 SPI2_CLK 24 ISH_SPI2_CS0

25 GND 26 ISH_SPI2_CS1

27 I2C0_SDA 28 I2C0_SCL
