OLIMEX© 2015 A20-OLinuXino-LIME user's manual
1.4 Board version used in the manual
Revision C boards and resources were used while writing this document. It is possible that they are
outdated so it is always recommended to download the latest sources from the GitHub page of the
board (https://github.com/OLIMEX/OLINUXINO/tree/master/HARDWARE).
Please note that A20-OLinuXino-LIME design is almost identical to the design of its predecessor
A10-OlinuXino-LIME – the only difference being the processor. Even then the processors are pin-
to-pin compatible. Some peripherals, documents or software may be suitable for both the A20 and
the A10 LIME boards but it is generally advised to use resources for the specific board.
1.5 Document organization
Each section in this document covers a separate topic, organized as follows:
– Chapter 1 is an overview of the board usage and features
– Chapter 2 provides a guide for quickly setting up the board and software notes
– Chapter 3 contains the general board diagram and layout
– Chapter 4 describes the component that is the heart of the board: the A20 – Allwinner
processor
– Chapter 5 is an explanation of the control circuitry associated with the microcontroller
– Chapter 6 covers the connector pinout, peripherals and jumper description
– Chapter 7 provides the schematics and the dimensions of the board
– Chapter 8 contains the revision history, useful links and support information
Page 7 of 49
