Water leaks
Check the evaporator and the external water circuit on water
leaks.
Drain disposal
Put the service covers in place so that the unit is completely
closed, and start up the unit. After a few hours of operation,
check if the condensing water is evacuated properly through the
drain and that it does not flow over from the drain pan on the
floor.
It may happen that the drain pan outlet is obstructed or that the
condenser fans create a vacuum so that the condensing water
remains in the drain pan and flows over. In this case, the drain
disposal should be lowered. The level difference of 75 mm
indicated in the chapter “Installing the unit” is a minimum.
3 If the unit does not start after a few minutes, consult the actual
operational information available in the list of direct parameters.
Also refer to the chapter "Troubleshooting" on page 17.
Switching the unit off
To switch the unit off and cooling mode is active, proceed as follows:
1 Press the D key for approximately 5 seconds, the G LED will
be extinguished.
How to consult and modify the direct parameters
For an overview of the menu structure, refer to "Menu overview" on
page 20.
1 Press B for 5 seconds in the main display.
The -/- parameter group is displayed.
2 Press the C or D key to select the required parameter
group.
3 Press the B key to enter the selected parameter group.
4 Press the C or D key to select the required parameter.
5 Press the B key to consult the selected parameter.
6 Press the C or D key to raise, respectively lower the
setting of the selected parameter. (Only valid for read/write
parameters.)
7 Press the B key to confirm the modified setting.
OR
Press the A key to cancel the modified setting.
8 Press the A key to return to the parameter group.
9 Press 2 times the A key to return to the main display.
If during the procedure no buttons are pressed for 30 seconds, the
displayed parameter code or value will start flashing. After another
30 seconds without pressing any buttons, the controller automatically
returns to the main display without saving any modified parameter.
How to consult the "sensor readout menu" parameters
For an overview of the menu structure, refer to "Menu overview" on
page 20.
The b01/b02/b03 parameters are part of the "sensor readout
menu".
1 Press the C or D key in the main display.
The b01 parameter is displayed.
In case no buttons are pressed, the value of the b01 sensor will
be displayed until C or D is pressed again to select
another parameter (b02 or b03).
2 Press the A key to return to the main display.
If during the procedure no buttons are pressed for 30 seconds, the
displayed parameter code or value will start flashing. After another
30 seconds without pressing any buttons, the controller automatically
returns to the main display.
Adjusting the cooling temperature setpoint
1 Modify the r1 cooling setpoint parameter.
This is a direct parameter, refer to "How to consult and modify the
direct parameters" on page 11.
Consulting actual operational information
The actual operational information that can be consulted in the list of
direct parameters consists of:
■ b01:Evaporator inlet water temperature,
■ b02:Evaporator outlet water temperature,
■ b03: Not used,
■ c10:Total running hours of the compressor 1,
■ c15:Total running hours of the pump.
These are direct parameters, refer to "How to consult and modify the
direct parameters" on page 11.
Resetting alarms
When an alarm is detected, the following happens:
■ the alarm relay is energized,
■ the H LED is displayed
■ the display starts flashing, alternately showing the alarm code
and the inlet water temperature.
The following alarm codes may appear on the screen:
■ a1: indicates an anti-freeze alarm.
■ e1: indicates that the NTC probe used to measure the
evaporator inlet water temperature is defective.
■ e2: indicates that the NTC probe used to measure the
evaporator outlet water temperature is defective.
■ e3: indicates that the fuse for the evaporator heatertape (F4)
is blown or that there is a reverse phase error or that there
is a problem with the I/O PCB (A2P).
NOTE
In case of remote on/off control (h07=1), it is recom-
mended to install an on/off switch near the unit in
series with the remote switch. The unit can then be
switched off from either place.
NOTE
If remote on/off control is enabled, refer to "Selecting
local or remote on/off control" on page 14.
NOTE
When dual setpoint is enabled (refer to "Selecting dual
setpoint control" on page 14).
NOTE
■ The parameters b01, b02 and b03 can also be
consulted by the "sensor readout menu". Refer to
"How to consult the "sensor readout menu"
parameters" on page 11.
■ To reset the timers of parameters c10, c11 and
c15 refer to "Resetting warnings" on page 12.
