Advanced features of the digital controller
This chapter gives an overview and a brief functional description of
the screens provided by the different menus. In the following chapter,
you will find how you can set up and configure the unit using the
various menu functions.
All menus are directly accessible using the corresponding key on the
digital controller. The down arrow X on the display indicates that you
can go to the next screen of the current menu using the h key. The
up arrow W on the display indicates that you can go to the previous
screen of the current menu using the g key. If C is displayed, this
indicates that you can either return to the previous screen or can go
to the next screen.
Readout menu
Setpoints menu
Depending upon the settings in the user settings menu and on the
selected cooling/heating operation mode, the "setpoints" menu can
either be entered directly or by means of the user password.
User settings menu
The "user settings" menu, protected by the user password, allows a
full customization of the units.
To consult actual operational informa-
tion about the control mode, the inlet
and outlet water temperature of the
evaporator and inlet water temperature
of the condenser.
Note that for a DICN system, the
and
values are
the values of the individual units, not of
the system. Temperatures of the system
can be consulted in the first screen of
the network menu.
To consult information about the outlet
water temperature of the evaporator of
circuit 1 and 2 (only for
EWWD360~540).
To consult information about the unit
status and the thermostat step.
To consult information about the
pressures of circuit 1.
To consult information about the
pressures of circuit 2 (only for
EWWD360~540).
To consult actual operational informa-
tion about the total running hours of the
compressors and the number of
compressor starts.
To consult actual operational informa-
tion about the total running hours of the
compressors in cooling mode and in
heating mode.
To define the temperature setpoints.
() $!
$!
$"$!
#$$!
(*
$"$!
$"$!
(*
$$$+
(*
,$- . '$/!
%%- . '!
(*
,$- . '$/!
%%- . '!
(* 0
$$$$$1 $$$$$
$$$$$1 $$$$$
(2 0
$$$$$1 $$$$$1
$$$$$1 $$$$$1
$!
$!
$"$!
$"$!
To define the manual settings and to
activate or deactivate manual control
mode.
To define the thermostat settings.
To define the lead-lag mode of both
circuits (only for EWWD360~540).
To define the capacity limitations. (first
screen)
To define the capacity limitations.
(second screen)
To define the pump control settings.
To define the schedule timer.
To define the dual evaporator pump.
To define the display settings (first
screen).
To define the display settings (second
screen).
To define the number of slaves for a
“master” unit. This menu can only be
accessed at the "master" unit!
The controller displays the name of the
unit:
,
...
#
. This
name is automatically assigned depen-
ding on the set hardware address.
Refer to "Setting the adresses" in
"Connection and setup of a DICN
system" in the installation manual.
To define whether or not a password is
needed to enter the setpoints menu.
To enter the service menu (only a
qualified installer is allowed to access
this menu).
()
"$+ $$+
(*
$%/3$%3
(*
$$$1
4
(*
$$+$$+
$$+$$+
(*
#$$+$$+
%$$+$$+
(*
$$3
$$$3
1$$
(*
(* $ $#
$$$$$ $$$$
$$$$$ $$$$
$#$$$$ $$$$
(*
$%/1
(*
(*
$$1$$
$$$
(*
(*
$$$$1
(*
(2
$$$$
