Operation manual
3
EWWD120~540MBYNN
Packaged water-cooled water chillers
4PW22685-1B
D
ESCRIPTION
The EWWD water-cooled water chillers are available in 9 standard sizes.
Figure -
Main components
1 25431126
11 3 1
452
1000
850
500
600
700
900
30 29 12
17
14
21 20 28
30 29
29 1324 22 252327
28
23
22
12
13
10
10
178
89
9
14
19
19
7
26
6
67
29
18
9
16
15
15
24
300
EWWD120~280
EWWD360~540
1
Compressor
17
Leaving water temperature sensor
2
Evaporator
18
Discharge stopvalve
3
Condenser
19
Condensor entering water temperature sensor
4
Switchbox
20
Digital display controller
5
Compressor switchbox
21
Emergency stop
6
Air purge condenser
22
Power supply intake
7
Water drain condenser
23
Field wiring intake
8
Charge valve
24
Holes for lifting
9
Safety valve
25
Transportbeam
10
High pressure switch
26
Ballvalve liquid pipe
11
Drier
27
Main isolator switch (optional)
12
Chilled water in (Victaulic
®
coupling)
28
Filter
13
Chilled water out (Victaulic
®
coupling)
29
Counterpipe for welding
14
Condenser water out
30
Flowswitch
15
Condenser water in
16
Entering water temperature sensor Required space around the unit for service
