EWWD120~540MBYNN
Packaged water-cooled water chillers
4PW22685-1B
Operation manual
16
To check the actual value of the software timers, proceed as follows:
1 Enter the
. (Refer to the chapter "How to enter a
menu" on page 8.)
The controller displays the actual value of the
: the loadup timer, the loaddown timer, the flowstart
timer, the flowstop timer (when the unit is on and the flowstart
timer has reached zero), the pumplead timer and the pumplag
timer.
2 Press the h key to check the compressor timers.
The controller shows the actual value of the
: the guard timers (one per circuit) and the antirecycling
timers (one per circuit).
3 Press the h key to check the remaining timers.
The controller shows the actual value of the
.
Tasks of the safeties menu
Listing activated safeties and checking the unit status
If the alarm buzzer is activated and the user presses the p key, the
controller automatically enters the safeties menu.
■ The controller will enter the
screen of the safeties
menu when a unit safety was the cause of shutdown.
■ The controller will enter the
or
screen of the safeties menu when a safety of the circuit was
activated.
■ For a DICN system, the controller can also show:
. This occurs when the wrong
number of slave units is defined (refer to "Defining the network
settings" on page 15) or when a slave unit is missing (because
of bad connection or power supply failure).
Make sure to define the correct number of slave units and to
make correct connections.
■ When the unit is configured with a dual evaporator pump, the
controller will enter the
screen of the
safeties menu when a safety on the pump was the cause of
shutdown.
1 Press the p key when the alarm buzzer is activated.
The appropriate safety screen with the basic information
appears. Press the q key to see the detailed information. These
screens provide information about the unit status at the moment
of shutdown (see "Safeties menu" on page 12).
2 If more than one kind of safety is active (indicated by means of
W, X or C), use the g and h keys to consult them.
Tasks of the history menu
Checking the safety info and the unit status after a reset
The information available in the safeties menu is also stored in the
history menu, where it is stored after resetting the unit or the circuit.
In this way, the history menu provides a means of checking the unit
status at the moment of the latest shutdown.
To check the safety info and the unit status, proceed as follows:
1 Enter the
. (Refer to the chapter "How to enter a
menu" on page 8.)
The controller enters the last
screen which contains
basic information of the moment of this shutdown.
2 Press the g and h keys to consult the other present
screens.
3 Press the q key to see the detailed information.
Tasks of the info menu
Consulting additional unit information
1 Enter the
through the main menu. (Refer to the
chapter "How to enter a menu" on page 8).
The controller enters the
screen which
contains the following information: the time and date.
2 Press h to consult the first
screen.
This screen contains information about the unit name and the
refrigerant used.
3 Press h to consult the next
screen.
This screen contains information about the controller's software
version.
4 Press h to consult the
screen.
This screen contains information about the PCB.
Tasks of the input/output menu
Checking the status of the inputs and outputs
The input/output menu provides a means of checking the status of
the digital inputs and the status of the relay outputs.
The locked digital inputs are:
■
: whether the emergency button has been
pressed.
■
: indicates the status of the flowswitch: activated or
deactivated.
■
: indicates the actual status of this
safety.
■
: indicates the actual status of
this safety.
■
: indicates the actual status
of this safety.
■
: indicates the actual status of this safety.
■
: indicates the actual
status of this safety.
■
: indicates the actual
status of this safety.
The changeable digital inputs are:
■
#%
: indicates the position of the "enable/
disable capacity limitation" switch.
■
: indicates the position of the remote dual
setpoint switch: setpoint 1 or setpoint 2.
■
: indicates the position of the remote on/off switch.
■
: indicates the position of the connected switch.
The locked relay outputs are:
■
: indicates whether circuit 1/2 is on/off.
■
: indicates whether circuit 1/2 is in
starmode or not.
■
: indicates whether circuit 1/2 is in
deltamode or not.
■
+
: indicates if the 12% capacity valve of circuit 1/2
is activated.
■
: indicates if the UP of the capacity control motor of
circuit 1/2 is activated.
■
: indicates if the DWN of the capacity control
motor of circuit 1/2 is activated.
■
: indicates the FEEDBACK of the potentiometer
of circuit 1/2 (Ω).
■
: indicates the status of this voltage free contact.
It is activated if the pump should be ON.
■
: indicates the status of this voltage free contact. It
is activated if there is any alarm on the unit.
NOTE
You can check the "found" slave units in the 2nd
screen of the network menu.
