11
Page
1 - Presentation....................................................... 11
2 - Description......................................................... 12
3 - DC and AC voltages (V DC and AC) ................ 13
4 - Decibels (dB) ..................................................... 13
5 - Currents (A DC and AC) ................................... 14
6 - Resistances (Ω) ................................................ 15
7 - Continuity sound test [
] .............................. 15
8 - General specifications ....................................... 15
9 - Accessories and spares (To order) ................. 16
10 - Warranty ............................................................ 16
11 - Maintenance ...................................................... 17
12 - Appendix ............................................................ 42
CONTENTS
1 - PRESENTATION
The C.A 5005 multimeter is designed for the daily needs of
professionals in electricity. It has the following functions:
- Voltmeter: voltage measurements (V DC and AC)
- DC ammeter: measurement of DC currents directly (A DC)
- AC ammeter: measurement of AC currents with current clamp
(A AC
)
- Ohmmeter: resistance measurements (
ΩΩ
ΩΩ
Ω)
- Continuity sound test [
]
It also allows the measurement of decibel levels (dB), on the AC
voltmeter ranges.
The dial has a fuse test light (Fus.) and “Voltest” light to check the
absence of voltage on ohmmeter.
NB: Always use accessories suited to the voltage and the overvoltage
category of the circuit to measure (to NF EN 61010).
