16
Use the designations and references below.
C.A 5005 ...................................................................... P01196523E
Supplied with a pair of leads with prods,
1 battery 9 V and this User’s manual.
Accessoires et rechanges
■ Shoulder bag (240 x 230 x 70 mm) ......................... P01298033
■ Carrying holster (220 x 180 x 75 mm) .................... P01298036
■ Pair of leads with test prods ................................... P01295456Z
■ Set of 10 fuses 1 A HBC (6.3 x 32 mm) .................. P01297039
■ Set of 10 fuses 10 A HBC (6.3 x 32 mm) ................ P01297038
Different measurement accessories widen the field of application or
confer new functions on your multimeter.
Documentation on request.
NB: Always use accessories suited to the voltage and the overvoltage
category of the circuit to measure (to NF EN 61010).
Our guarantee is applicable for three years after the date on which the
equipment is made available (extract from our General Conditions of
Sale, available on request).
10 - WARRANTY
8-2 Power supply
■ One battery 9 V (type 6F22 or 6LF22 alkaline)
■ Battery life:
- 10,000 measurements of 10 seconds with alkaline battery LR6
8-3 Environmental conditions
■ Temperature: use: -10°C to +55°C / storage: -40°C to +70°C
■ Relative humidity:
use: ≤ 90% RH / storage: ≤ 95% RH
■ Altitude: use < 2000 m
8-4 Conformity with international standards
8-4-1 Electrical safety (NF EN 61010-1)
■ Double insulation : ■ Installation category: III
■ Degree of pollution: 2 ■ Rated voltage: 600 V
8-4-2 Electromagnetic compatibility
Emission and Immunity (NF EN 61326-A1)
8-4-3 Mechanical protection
■ Degree of watertightness (NF EN 60529): protection index IP 53
9 - TO ORDER
