Automotive Multimeter
Introduction
1
Introduction
XWWarning
Read "Safety Information" before you use the
Meter.
The Model 88 V Automotive Multimeter (“the Meter”) is a
hand-held, battery-operated measurement device used for
voltage, continuity, resistance, current, diode, capacitance,
frequency, temperature, RPM, pulse width, and duty cycle
measurements.
Contacting Fluke
To contact Fluke, call one of the following telephone
numbers:
USA: 1-888-44-FLUKE (1-888-443-5853)
Canada: 1-800-36-FLUKE (1-800-363-5853)
Europe: +31 402-675-200
Japan: +81-3-3434-0181
Singapore: +65-738-5655
Anywhere in the world: +1-425-446-5500
For USA Service: 1-888-99-FLUKE
(1-888-993-5853)
Or, visit Fluke's Web site at www.fluke.com
.
To register your product, visit register.fluke.com
Safety Information
The Meter complies with:
• EN61010-1:2001
• ANSI/ISA S82.01-2004
• CAN/CSA C22.2 No. 1010.1:2004
• UL61010-1
• Measurement Category III, 1000 V, Pollution
Degree 2
• Measurement Category IV, 600 V, Pollution
Degree 2
In this manual, a Warning identifies conditions and
actions that pose hazards to the user. A Caution identifies
conditions and actions that may damage the Meter or the
equipment under test.
Electrical symbols used on the Meter and in this manual
are explained in Table 1.
