Model 88 V
Users Manual
8
Table 5. Pushbuttons
Button
Switch
Position
Function
N
Selects capacitance
M
Selects temperature
g K L
Selects measurement of RPM o or RPM n
e
Switches between dc and ac current
f
Switches between dc and ac current
A
(Yellow)
Power-up Disables automatic power-off feature (Meter normally powers off in 30 minutes).
The Meter reads
“PoFF” until A is released.
B
Any switch
position
Power-up
Starts recording of minimum and maximum values and disables power-off feature. Steps the
display through MAX, MIN, AVG (average), and present readings. Cancels MIN MAX (hold for 1
second).
Enables the Meter’s calibration mode and prompts for a password.
The Meter reads “
CAL“ and enters calibration mode. See the 80 Series V Callibration Manual for
more information
.
