B-3 Direct Current Current (DC Current)
Overload protection:
20µA
200µA
2mA
20mA
200mA
2A
10A
20A
0.01µA
0.1 µA
1 µA
10µA
100 µA
1mA
Range Resolution
UT51 UT 52 UT53 UT54 UT55
Accuracy
(2%+5)
(0.8%+1)
(1.5%+1 )
(0.8%+1)
10mA
(1.5%+1)
(2%+5)
(2%+5 )
For UT51:
2A, 250V fast acting fuse, φ5x20mm(below
2A range)
10A, 250V fast acting fuse,φ5x20mm(at 10A
range) .
For UT52/53/54/55:
315mA, 250V fast acting fuse, φ5x20mm (No
fuse at 20A range).
Max current input :
For UT51: 10A (The measurement time
for high current should be less than 10
seconds maximum, and the interval time
between two measurements should be greater
than 15 minutes.
For UT52/53/54/55: 20A (The measurement
time for high current should be less than 15
seconds maximum, and the interval time
between two measurements should be greater
than 15 minutes.
