Phase Angle (PG=acos (PF))

Range Accuracy Resolution Measuring Condition

~90

(capacitive or inductive)

±2

The minimum measuring current

10A

The minimum measuring voltage

45V

~90

(capacitive or inductive)

For reference only

Measuring current less than 10A

Measuring voltage less than 45V

Remarks:

 Allowable maximum overload protection voltage: 750V RMS

 Allowable maximum overload protection current: 1000A RMS

Basic Functions

Range

Best Accuracy

AC Voltage

100V/400V/750V

±(1.2%+5digits)

AC Current

40A/100A/400A/1000A

±(2%+5 digits)

Active Power

0.01kW

750kW

±(3%+5 digits)

Apparent Power

0.01kVA

750kVA

±(3%+5 digits)

Reactive Power

0.01kVAr

750kVAr

±(4%+5 digits)
