readings.

Press once to enter Memory Record mode, appears and the Meter beeps.

▼/▼

If the Meter steps through sum of power press

▼/▼

but

ton to

switch display of active

power (main display) , sum of reactive power (secondary display) , sum of power

factor (main display) and sum of apparent power.

In the MR mode, press ▼/▼ to select recoded data.

USB

Measurement data will be sent to the PC

2.1. Additional inforamtion

1. Turn the rotary switch deasil to make the position away from the OFF position. Hearing a

beep sound indicates the meter is turned on. The LCD displays all symbols firstly and then

return to the normal mode. If the symbol is displayed, please changed the battery.

2. After auto-shut-off, there are some parts of the circuit of the meter which is still work. If

no measurement needed in a longer time, you’d better turn the rotary switch back to the

OFF position.

3. Press the backlight button when needed. Auto shut-down backlight after lighting

18secs.Press the button again, turn the backlight off manually

3. Display symbols

Figure 1
