Getting Started

Before connecting and powering up the instrument, please review the instructions in this chapter.

2.1 Input Power and Fuse Requirements

The 5490C Series digital multimeters can operate on 110 V or 220 V with +/-10% tolerance at 60 Hz or

50 Hz. Before powering the instrument, please check for the correct power input setup that

corresponds to the line voltage to be used for operation. Note the label on the rear panel of the

instrument as shown below:

RATING

FUSE

~ 110V/60Hz

T1 AL

~ 220 V/50Hz

T500mAL

Table 2.1 – Fuse Table

Before connecting to an AC outlet or external power source, verify that the AC power cord, including

the extension line, is compatible with the rated voltage/current and that there is sufficient circuit

capacity for the power source. Once verified, connect the cable firmly.

The included AC power cord is safety certified for this

instrument operating in rated range. To change a

cable or add an extension cable, be sure that it can

meet the required power ratings for this instrument.

Any misuse with wrong or unsafe cables will void the

warranty.

SHOCK HAZARD:

The power cord provides a chassis ground through a

third conductor. Verify that your power outlet is of the

three-conductor type with the correct pin connected

to earth ground.
