viii
Safety Symbols
Refer to the user manual for warning information
to avoid hazard or personal injury and prevent
damage to instrument.
Electric Shock hazard
This is the AC mains connect/disconnect
mechanical power switch.
On (Power). This is the In position of the power
switch when instrument is ON.
Off (Power). This is the Out position of the power
switch when instrument is OFF.
Power standby. The unit is not completely
disconnected from the AC mains in off state.
Alternating current (line)
Chassis (earth ground) symbol
Ground terminal
Protective earth ground
CAUTION indicates a hazardous situation which, if
not avoided, will result in minor or moderate injury
WARNING indicates a hazardous situation which, if
not avoided, could result in death or serious injury
DANGER indicates a hazardous situation which, if
not avoided, will result in death or serious injury.
Содержание
- C series 5 ½ and 6 ½ digit multimeters 1
- Models 5492c 5492cgpib 5493c 5493cgpib 1
- User manual 1
- Safety summary 2
- Compliance statements 6
- Ce declaration of conformity 7
- Safety symbols 8
- Contents 9
- General information 11
- Operating environment 11
- Package contents 11
- Front panel overview 12
- Product dimensions 12
- Rear panel overview 13
- Getting started 14
- Input power and fuse requirements 14
- Check and or change fuse 15
- Carrying handle adjustment 16
- Front panel menu reference 17
- Front panel operation 17
- Change display mode 19
- Display 19
- Display label text 20
- Digit mask 21
- Probe hold function 21
- Basic measurements 22
- Dc voltage 22
- Screen capture and file transfer 22
- Ac voltage 24
- Dcv ratio 24
- Dc current 26
- Ac current 27
- Resistance 2w 2 wire 29
- Resistance 4w 4 wire 30
- Capacitance measurement 31
- Continuity 33
- Temperature test 34
- Frequency measurement 35
- Math functions 37
- Null operation 37
- Secondary measurement 37
- Statistics 37
- Db calculation 38
- Dbm calculation 38
- Percent 38
- Recall settings 39
- Save readings 39
- Save recall 39
- Save settings 39
- Power on 40
- Set the language 41
- Setting the buzzer and brightness 41
- Setting the date time 41
- Setting the format of the digital display 41
- System settings 41
- Interface 42
- Rs232 interface 42
- Rs232 interface operation 42
- Lan interface 45
- Usb device 45
- Usb host 45
- Usb interface 45
- Gpib bus 46
- Gpib interface 46
- General bus commands 48
- Setting the gpib address 48
- Setting through the interface 48
- Specifications 5492c 5492cgpib 49
- Specifications 5492c 5492cgpib 50
- Specifications 5493c 5493cgpib 51
- Specifications 5493c 5493cgpib 52
- Specifications 5493c 5493cgpib 53
- Supplementary specifications 5493c 5493cgpib 54
- Service information 55
- Limited three year warranty 56
