DMTA053-01EN, Rev. D, July 2017
Important Information — Please Read Before Use 5
Presence of Visual Interferences or Phantom Spots
Presence of strong electromagnetic interference could generate noise in the signal that
is visually detectable. This interference is temporary and random in comparison with
the signals generated by the physical features of the inspected part, which are
coherent and persistent. This interference depends greatly on the nature, strength,
and proximity of the electromagnetic source and it will only disappear when the
source of the noise is no longer emitting signals.
Safety Symbols
The following safety symbols might appear on the instrument and in the instruction
manual:
General warning symbol
This symbol is used to alert the user to potential hazards. All safety messages that
follow this symbol shall be obeyed to avoid possible harm or material damage.
Shock hazard caution symbol
This symbol is used to alert the user to potential electric shock hazards. All safety
messages that follow this symbol shall be obeyed to avoid possible harm.
Safety Signal Words
The following safety symbols might appear in the documentation of the instrument:
IMPORTANT
