Olympus MultiScan MS 5800 Инструкция онлайн [8/160] 528325

DMTA053-01EN, Rev. D, July 2017

Labels and Symbols2

To avoid the risk of electric shock, do not touch the inner conductor of the BNC (or

LEMO) connectors. Up to 300 V can be present on the inner conductor. The warning

symbol near the connectors warns of this electric shock risk.

CAUTION

Warning symbol
