Инструкция по эксплуатации Страница: 11

CHAUVIN ARNOUX CA-F201 [11/36] Measurement capacity exceeded o l

Ampere

Ohm

Milli- prefix

Kilo- prefix

Compensation of the resistance of the leads

Continuity test

Diode test

Permanent display (automatic switching off de-activated)

Spent battery indicator

1.3.2 Measurement capacity exceeded (O.L)

The O.L (Over Load) symbol is displayed when the display capacity is exceeded.

1.4 THE TERMINALS

The terminals are used as follows:

1 2

Figure 5 : the terminals

Item Function

Cold terminal (COM)

Hot terminal (+)
