CHAUVIN ARNOUX CA-F201 [31/36] Characteristics of construction
![CHAUVIN ARNOUX CA-F201 [31/36] Characteristics of construction](/views2/1665964/page31/bg1f.png)
4.4 CHARACTERISTICS OF CONSTRUCTION
Housing Rigid polycarbonate shell with moulded elastomer covering
Jaws
Polycarbonate
Opening: 34 mm
Clamping diameter: 34 mm
Screen
LCD display unit
Dimension: 28 x 43.5 mm
Dimension H-222 x W-78 x D-42 mm
Weight 340g (with the battery)
4.5 POWER SUPPLY
Battery 1 x 9 V LF22
Mean life >130 hours
Duration of operation before
automatic switching off
After 10 minutes without action on the switch
and/or keys
4.6 COMPLIANCE WITH INTERNATIONAL STANDARDS
Electric safety
Compliant with standards IEC-61010-1, IEC-61010-2-
30, and IEC-61010-2-32:
1000V CAT-III or 600V CAT IV.
Electromagnetic
compatibility
Compliant with standard EN-61326-1
Classification: residential environment
Mechanical strength
Free fall: 2m (in accordance with standard IEC-68-2-32)
Level of protection
of the housing
IP40 (per standard IEC-60529)
