1-8 Internal Connectors
Readthefollowingguidelinesbeforeconnectingexternaldevices:
• First make sure your devices are compliant with the connectors you wish to connect.
• Before installing the devices, be sure to turn off the devices and your computer. Unplug the power
cord from the power outlet to prevent damage to the devices.
• After installing the device and before turning on the computer, make sure the device cable has
been securely attached to the connector on the motherboard.
1) ATX_12V_2X2
2) ATX_12V_2X4
3) ATX
4) CPU_FAN
5) SYS_FAN1/2
6) SYS_FAN3_PUMP
7) CPU_OPT
8) LED_C
9) SATA3 0/1/2/3/4/5
10) M2A/M2P
11) F_PANEL
12) F_ AUDIO
13) SPDIF_O
14) F_USB30
15) F_USB
16) COM
17) TPM
18) THB_C
19) CLR_CMOS
20) BAT
21) CPU/DRAM/VGA/BOOT
116
14
3
9
5
15 101712 13 8
21
16
21
19
20
18
10
5
47
- 13 -
