Gigabyte Z390 GAMING SLI [42/48] C 2 uefiraidconfiguration

C-3.ConguringLegacyRAIDROM

Enter the Intel

®

legacyRAIDBIOSsetuputilitytocongureaRAIDarray.Skipthisstepandproceedwiththe

installationofWindowsoperatingsystemforanon-RAIDconguration.

Steps:

1. In BIOS Setup, go to BIOS and set CSM Support to Enabled and StorageBootOptionControl to Legacy.

Next, go to Peripherals\SATAAndRSTConguration and make sure UseRSTLegacyOROM is set

to Enabled. Save the changes and exit BIOS Setup. After the POST memory test begins and before the

operatingsystembootbegins,lookforamessagewhichsays"Press<Ctrl-I>toenterCongurationUtility".

the hard drives being installed). Press <Enter> to proceed.

4. Under Disksitem,selecttheharddrivestobeincludedintheRAIDarray.Ifonlytwoharddrivesareinstalled,

theywillbeautomaticallyassignedtothearray.Setthestripeblocksizeifnecessary.Thestripeblocksize

canbesetfrom4KBto128KB.Onceyouhaveselectedthestripeblocksize,press<Enter>.

5. Enter the array capacity and press <Enter>. Finally press <Enter> on the Create Volume item to begin

creatingtheRAIDarray.Whenpromptedtoconrmwhethertocreatethisvolume,press<Y>toconrmor

<N> to cancel.

6. Whencompleted,youcanseedetailedinformationabouttheRAIDarrayintheDISK/VOLUMEINFORMATION

section,includingtheRAIDlevel,stripeblocksize,arrayname,andarraycapacity,etc.ToexittheRAID

BIOS utility, press <Esc> or select 6.Exit in MAINMENU.

RAIDVolumescreen.Enteravolumenamewith1~16letters(letterscannotbespecialcharacters)underthe

Nameitemandpress<Enter>.Then,selectaRAIDlevel.RAIDlevelssupportedincludeRAID0,RAID1,

RAID10,andRAID5(theselectionsavailabledependonthenumberoftheharddrivesbeinginstalled).

Next, use the down arrow key to move to Select Disks.

4. Under Select Disksitem,selecttheharddrivestobeincludedintheRAIDarray.Pressthe<Space>key

ontheharddrivestobeselected(selectedharddrivesaremarkedwith"X").Thensetthestripeblocksize.

Thestripeblocksizecanbesetfrom4KBto128KB.Onceyouhaveselectedthestripeblocksize,setthe

volume capacity.

5. After setting the capacity, move to Create Volume and press <Enter> to begin.

6. After completing, you'll be brought back to the Intel(R)RapidStorageTechnology screen. Under RAID

- 42 -
