- 4 -
B460M GAMING HD Motherboard Layout
* The box contents above are for reference only and the actual items shall depend on the product package you obtain.
The box contents are subject to change without notice.
Box Contents
5 B460M GAMING HD motherboard
5 Motherboard driver disc 5 Two SATA cables
5 User's Manual 5 I/O Shield
KB_MS
CPU_FAN
SYS_FAN
LGA1200
ATX
B460M GAMING HD
LED_C
AUDIO
DDR4_1
DDR4_2
BAT
ATX_12V_2X4
Intel
®
B460
F_U32
U32_2
U32_1
CODEC
CLR_CMOS
M_BIOS
VGAHDMI
USB_LAN
PCIEX16
PCIEX1
iTE
®
Super I/O
Realtek
®
GbE LAN
SATA3
1 3
0 2
M2M_PCH
426080
F_USB2COM F_PANEL
SPI_TPMF_AUDIO F_USB1
