1-5 Installing an Expansion Card

Readthefollowingguidelinesbeforeyoubegintoinstallanexpansioncard:

• Make sure the motherboard supports the expansion card. Carefully read the manual that came

with your expansion card.

• Always turn off the computer and unplug the power cord from the power outlet before installing an

expansion card to prevent hardware damage.

1-6 Back Panel Connectors

PS/2 Keyboard and PS/2 Mouse Port

Usetheupperport(green)toconnectaPS/2mouseandthelowerport(purple)toconnectaPS/2keyboard.

TheDVI-DportconformstotheDVI-Dspecicationandsupportsamaximumresolutionof1920x1200@60Hz

(theactualresolutionssupporteddependonthemonitorbeingused).Connectamonitorthatsupports

DVI-Dconnectiontothisport.

HDMI Port

TheHDMIportsupportsHDCP2.2

(Note2)

andDolbyTrueHDandDTSHD

MasterAudio formats.It alsosupports upto 192KHz/16bit 8-channelLPCM

audiooutput.YoucanusethisporttoconnectyourHDMI-supportedmonitor.Themaximumsupported

resolutionis4096x2160@60Hz

(Note1) TheDVI-DportdoesnotsupportD-Subconnectionbyadapter.

(Note2) ActualsupportmayvarybyCPU.
