Gigabyte B450M GAMING [11/42] Mic in center subwoofer speaker out pink

RJ-45 LAN Port

The Gigabit Ethernet LAN port provides Internet connection at up to 1 Gbps data rate. The following

describesthestatesoftheLANportLEDs.

Tocongure7.1-channelaudio,youhavetouseanHDfrontpanelaudiomoduleandenablethe

multi-channel audio feature through the audio driver.

• Whenremovingthecableconnectedtoabackpanelconnector,rstremovethecablefromyour

device and then remove it from the motherboard.

• Whenremovingthecable,pullitstraightoutfromtheconnector.Donotrockitsidetosideto

prevent an electrical short inside the cable connector.

AudioJackCongurations:

Jack

Headphone/

2-channel

4-channel 5.1-channel 7.1-channel

LineIn/RearSpeakerOut

a a a

Line Out/Front Speaker Out

a a a a

Mic In/Center/Subwoofer Speaker Out

a a

Front Panel Line Out/Side Speaker Out

PleasevisitGIGABYTE'swebsitefordetailsonconguringtheaudiosoftware.

USB 2.0/1.1 Port

TheUSBportsupportstheUSB2.0/1.1specication.UsethisportforUSBdevices.

Line In/Rear Speaker Out (Blue)

The line in jack. Use this audio jack for line in devices such as an optical drive, walkman, etc.

Line Out/Front Speaker Out (Green)

The line out jack.

Mic In/Center/Subwoofer Speaker Out (Pink)

The Mic in jack.

ActivityLED

Connection/

SpeedLED

LAN Port

ActivityLED:Connection/SpeedLED:

State Description

Orange 1 Gbps data rate

Green 100 Mbps data rate

Off 10 Mbps data rate

State Description

Blinking Datatransmissionorreceivingisoccurring

Off No data transmission or receiving is occurring

- 11 -
