1-2 ProductSpecications
CPU AMD Socket AM4, support for:
3rd Generation AMD Ryzen
™
processors/
2nd Generation AMD Ryzen
™
processors/
2nd Generation AMD Ryzen
™
with Radeon
™
Vega Graphics processors/
AMD Ryzen
™
with Radeon
™
Vega Graphics processors
(Go to GIGABYTE's website for the latest CPU support list.)
Chipset AMD X570
Memory 3rd Generation AMD Ryzen
™
processors:
- Support for DDR4 3200/2933/2667/2400/2133 MHz memory modules
2nd Generation AMD Ryzen
™
processors/2nd Generation AMD Ryzen
™
with
Radeon
™
Vega Graphics processors/AMD Ryzen
™
with Radeon
™
Vega Graphics
processors:
- Support for DDR4 2933/2667/2400/2133 MHz memory modules
2 x DDR4 DIMM sockets supporting up to 64 GB (32 GB single DIMM capacity)
of system memory
Dual channel memory architecture
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Support for Extreme Memory Prole (XMP) memory modules
(Go to GIGABYTE's website for the latest supported memory speeds and memory
modules.)
Onboard
Graphics
(Note 1)
Integrated Graphics Processor:
- 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz
* Support for DisplayPort 1.2 version.
- 2 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
* Support for HDMI 2.0 version, HDCP 2.2, and HDR.
Support for up to 3 displays at the same time
Maximum shared memory of 16 GB
Audio Realtek
®
ALC1220-VB codec
* The back panel line out jack supports DSD audio.
High Denition Audio
2/4/5.1/7.1-channel
* To congure 7.1-channel audio, you have to use an HD front panel audio module and
enable the multi-channel audio feature through the audio driver.
LAN Intel
®
GbE LAN chip (10/100/1000 Mbit)
Wireless
Communication
Module
Intel
®
Wi-Fi 6 AX200
- WIFI a, b, g, n, ac with wave 2 features, ax, supporting 2.4/5 GHz Dual-
Band
- BLUETOOTH 5
- Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate
* Actual data rate may vary depending on environment and equipment.
(Note 1) For 2nd Generation AMD Ryzen
™
with Radeon
™
Vega Graphics processors/AMD Ryzen
™
with Radeon
™
Vega Graphics processors only.
- 6 -
