Gigabyte Z390 DESIGNARE (rev. 1.0) [103/128] 2 9 ambient led

Unique Features

- 103 -

5-2-9 Ambient LED

This application allows you to enable or specify the lighting mode of the onboard LEDs while in the Windows

environment.

The Ambient LED Interface

Using Ambient LED

• The icon on the top right corner:

Allows you to enable or disable the LED lighting.

• Allows to you to congure the lighting behaviour of all LEDs.

Still Mode All LEDs emit a single color.

Beat Mode All LEDs are synchronized with your music.

Flash Mode All LEDs simultaneously ash on and off.

Pulse Mode All LEDs simultaneously fade in and fade out.

Color Cycle Mode All LEDs simultaneously cycle through a full spectrum of colors.

Double Flash Mode All LEDs ash in an interlaced pattern.

LED Color Theme Select the LED color.
