Gigabyte H410M S2 [12/40] 7 internal connectors
![Gigabyte H410M S2 [12/40] 7 internal connectors](/views2/1667905/page12/bgc.png)
1-7 Internal Connectors
Read the following guidelines before connecting external devices:
• First make sure your devices are compliant with the connectors you wish to connect.
• Before installing the devices, be sure to turn off the devices and your computer. Unplug the power
cord from the power outlet to prevent damage to the devices.
• After installing the device and before turning on the computer, make sure the device cable has
been securely attached to the connector on the motherboard.
1) ATX_12V_2X4
2) ATX
3) CPU_FAN
4) SYS_FAN
5) LED_C
6) SATA3 0/1/2/3
7) F_PANEL
8) F_ AUDIO
9) F_U32
10) F_USB1
11) COM
12) SPI_TPM
13) CLR_CMOS
14) BAT
4 1 3
2
9
13
10
14
75
8
6
1211
- 12 -
