Gigabyte Z370XP SLI (rev. 1.0) [11/48] 7 back panel connectors

1-7 Back Panel Connectors

PS/2 Keyboard and PS/2 Mouse Port

Use the upper port (green) to connect a PS/2 mouse and the lower port (purple) to connect a PS/2 keyboard.

USB 3.1 Gen 1 Port

TheUSB3.1Gen1portsupportstheUSB3.1Gen1specicationandiscompatibletotheUSB2.0

specication.UsethisportforUSBdevices.

USB 3.1 Gen 2 Type-A Port (Red)

TheUSB3.1Gen2Type-AportsupportstheUSB3.1Gen2specicationandiscompatibletotheUSB

3.1Gen1andUSB2.0specication.UsethisportforUSBdevices.

Audioformats.Italsosupportsupto192KHz/16bit8-channelLPCMaudio

output. You can use this port to connect your HDMI-supported monitor. The maximum supported

resolutionis 4096x2160@30 Hz,butthe actual resolutions supportedaredependent on the monitor

being used.

After installing the HDMI device, make sure to set the default sound playback device to HDMI. (The

item name may differ depending on your operating system.)

RJ-45 LAN Port

The Gigabit Ethernet LAN port provides Internet connection at up to 1 Gbps data rate. The following

describes the states of the LAN port LEDs.

Activity LED

Center/Subwoofer Speaker Out (Orange)

Usethisaudiojacktoconnectcenter/subwooferspeakersina5.1/7.1-channelaudioconguration.

Rear Speaker Out (Black)

Usethisaudiojacktoconnectrearspeakersina7.1-channelaudioconguration.

Side Speaker Out (Gray)

Usethisaudiojacktoconnectsidespeakersina4/5.1/7.1-channelaudioconguration.
