Daikin EWLDС13I-SS [25/36] Evaporator and condenser pressure drops
![Daikin EWLD850I-SS [25/36] Evaporator and condenser pressure drops](/views2/1667993/page25/bg19.png)
25
Evaporator and condenser pressure drops
EWLD~I-SS
320 400 420 500 600 650 750 800 850 900
Cooling Capacity (kW)
328 391 428 504 596 657 730 788 850 919
Water Flow (l/s)
15.67 18.68 20.45 24.08 28.48 31.39 34.88 37.65 40.61 43.91
Evaporator Pressure Drops (kPa)
34 47 47 54 49 39 52 47 47 45
Water flow and pressure drop referred to nominal condition: evaporator water in/out: 12/7°C – saturated discharge temperature: 45°C
950 C10 C11 C12 C13 C14 C15 C16 C17
Cooling Capacity (kW)
966 1033 1078 1125 1188 1267 1319 1370 1422
Water Flow (l/s)
46.15 49.35 51.50 53.75 56.76 60.53 63.02 65.46 67.94
Evaporator Pressure Drops (kPa)
45 52 46 49 41 51 55 59 63
Water flow and pressure drop referred to nominal condition: evaporator water in/out: 12/7°C – saturated discharge temperature: 45°C
To determinate the evaporator or condenser pressure drop for different versions or at different working
condition, please refer to the following formula:
PD2 (kPa) = PD1 (kPa) x
where:
PD2 Pressure drop to be determinated (kPa)
PD1 Pressure drop at nominal condition (kPa)
Q2 water flow at new working condition (l/s)
Q1 water flow at nominal condition (l/s)
How to use the formula: Example (evaporator)
The unit EWLD320I-SS has been selected for working at the following conditions:
- Evaporator water in/out: 11/6°C
- Saturated discharge Temperature: 40°C
The cooling capacity at these working conditions is: 333 kW
The evaporator water flow at these working conditions is: 15.91 l/s
The unit EWLD320I-SS at nominal working conditions has the following data:
- evaporator water in/out: 12/7°C
- Saturated discharge Temperature: 45°C
The cooling capacity at these working conditions is: 328 kW
The evaporator water flow at these working conditions is: 15.67 l/s
The evaporator pressure drop at these working conditions is: 34 kPa
The evaporator pressure drop at the selected working condition will be:
PD2 (kPa) = 34 (kPa) x
PD2 (kPa) = 35 (kPa)
NOTE
If the calculated evaporator water pressure drop is below 10 kPa or above 100 kPa please contact the factory for dedicated
evaporator.
15,91
(l/s)
15.67
(l/s)
1.8
1.8
Q
2
(l/s)
Q
1
(l/s)
