Daikin EWLDС13I-SS [26/36] Dimensions
![Daikin EWLD600I-SS [26/36] Dimensions](/views2/1667993/page26/bg1a.png)
26
Dimensions
EWLD320÷500I-SS
M
40
L
182
I
412
H
637
G
1837
F
809
E
1500
D
805
C
1899
B
3114
Dimensions
A
1468
Models
EWLD~I-
320÷500I-SS
LEGEND
1 - Electrical Panel
2 - Power connections slot 150x200
3 - Four (4) holes Ø21 for isolator mounting
4 - Evaporator water inlet (Victaulic connection) [168.3mm]
5 - Evaporator water outlet (Victaulic connection) [168.3mm]
6 - Isolators (optional)
7 - Liquid line inlet connection [Ø42]
8 - Dischar
g
e line connection
[
Ø88.9
]
7X 7Y 7Z
7 I 145 1418 63
8X 8Y 8Z
8 I 1960 827 C
