28
EWLDC10÷C17I-SS
M
40
L
446
I
880
H
656
G
2910
F
1198
E
2200
D
1041
C
2415
B
4427
Dimensions
A
2128
Models
EWLD~I-
C10÷C17I-SS
LEGEND
1 - Electrical Panel
2 - Power connections slot 150x350
3 - Four (4) holes Ø21 for isolator mounting
4 - Evaporator water inlet (Victaulic connection) [219.1mm]
5 - Evaporator water outlet (Victaulic connection) [219.1mm]
6 - Liquid line inlet connection [Ø42]
7 - Discharge line connection [Ø88.9]
8 - Isolators (optional)
6X 6Y 6Z
6 I 350 2080 130
6 II
350 2080 130
6 III 315 2080 130
7X 7Y 7Z
7 I 1120 549 2415
7 II 1776 549 2415
7 III 1120 1373 1645
