Refrigerant circuit
Each circuit shall include as standard: electronic expansion device piloted by unit’s microprocessor control, compressor
discharge shut-off valve, suction line shut-off valve, replaceable core filter-drier, sight glass with moisture indicator and
insulated suction line.
Control panel
9 Field power connection, control interlock terminals, and unit control system should be centrally located in an electric
panel (IP 54). Power and starting controls should be separate from safety and operating controls in different
compartments of the same panel.
9 Starting shall be Wye-Delta type as standard.
9 Operating and safety controls should include energy saving control; emergency stop switch; overload protection for
compressor motor; high and low pressure cut-out switch (for each refrigerant circuit); anti-freeze thermostat; cut-out
switch for each compressor.
9 All of the information regarding the unit will be reported on a display and with the internal built-in calendar and clock
that will switch the unit ON/OFF during day time all year long.
9 The following features and functions shall be included:
- resetting chilled water temperature
by controlling the return water temperature or by a remote 4-20 mA DC
signal or by controlling the external ambient temperature;
- soft load function
to prevent the system from operating at full load during the chilled fluid pulldown period;
- password protection
of critical parameters of control;
- start-to-start and stop-to-star timers
to provide minimum compressor off-time with maximum motor protection;
- communication capability
with a PC or remote monitoring;
- discharge pressure control
through intelligent cycling of condenser fans;
- lead-lag selection
by manual or automatically by circuit run hours;
- double set point
for brine unit version;
- scheduling
via internal time clock to allow programming of a yearly start-stop schedule accommodating
weekends and holidays.
Optional High Level Communications Interface
The controller as a minimum shall be capable of providing the data shown in the above list, using the following options:
- RS485 Serial card
- RS232 Serial card
- LonWorks interface to FTT10A Transceiver.
- Bacnet Compatible
- Use of Compass Points (manufactured by North Communications) to allow communications with such as Honeywell,
Satchwell, Johnson Controls, Trend etc.
