![CHAUVIN ARNOUX CA-6524 [10/38] On the back](/img/pdf.png)
CHAUVIN ARNOUX CA-6524 [10/38] On the back
![CHAUVIN ARNOUX CA-6524 [10/38] On the back](/views2/1668769/page10/bga.png)
10
1.4.4. ON THE BACK
Captive quarter-turn screw.
Battery compartment cover.
Prop.
Magnet for attachment to a metallic surface (for the
C.A 6524 and the C.A 6526).
Non-skid pads.
