EXTECH MG310 [5/12] Display description

5 MG310-en-GB_V1.0 12/15

1234567

101112

DisplayDescription

1. Batterystrengthindicator

2. DC/ACVoltagemodes

3. Voltagepresentalert

4. PItestmode

5. DARtestmode

6. Time1forPI/DARtests

7. Time2forPI/DARtests

8. PI/DARTesttimer(minutesandseconds)

9. Testvoltageoutput[V]

10. Units[G:Gigaohm;M:Megaohm]andVoltage[V]

andResistance[Ω]modesymbols

11. Mainmeasurementdisplay

12. ZEROfunction

13. UnderRange<

14. OverRange>

15. Audiblecontinuityalertbeeper

OperatingInstructions

WARNING:Riskofelectrocution.High‐voltagecircuits,bothACandDC,areverydangerousand

shouldbemeasuredwithgreatcare.

1. ALWAYSturnthefunctionswitchtotheOFFpositionwhenthemeterisnotinuse.

2. If“OL”appearsinthedisplayduringameasurement,thevalueexceedsthemeter’srange.

3. Ifthebatteriesareweakreplacethembeforeperformingtests.Thebatteryindicatoron the

upperleft

alertstheuserwhenbatterypowerislow.Thebatterycompartmentisaccessed

throughthebackofthemetersecuredbyonePhillipsheadscrew.

DISPLAYBACKLIGHT

Pressandholdthebacklightbuttonfor2secondstoswitchthebacklightonoroff.Forbest

batteryefficiencyusethebacklightonlywhenneeded.

HOLD

Theautomaticholdfunctionfreezestheinsulationresistancereadinginthedisplayforashort

periodoftimeforconvenience.



LOWBATTERYINDICATION

Whenthe iconappearsinthedisplay,thebatteriesshouldbereplaced.Refertothebattery

replacementsectionofthisusermanual.
