Description

1. Negative High Voltage (HV) Terminal

(Earth Ground)

2. Dot Matrix Display window

3. GUARD connection Terminal

4. Positive High Voltage Line Terminal

5. 10KV test voltage preset button

6. Power OFF button

7. Voltage adjustment button (-)

8. 5KV test voltage preset button

9. TEST START/STOP button

10. 2.5KV test voltage preset button

11. 500V test voltage adjust button (+)

12. Power ON button

13. 1KV test voltage preset button

Note: Battery compartment located on bottom of instrument and test lead compartment

located behind the upper faceplate.
